Black Pearl 7" HD 1024 Screen

The 3DR 7-inch FPV monitor is ideal for capturing real-time mission images in the field. Even on the brightest days, the monitor is easy to see – with sharp contrasts and a LED backlight. The 5.8 GHz 32-channel wireless video receiver won’t display a "blue screen" when the signal gets weak. This means you can fly farther without losing your first person view.

Small, lightweight and powerful, you can view two channels simultaneously for serious mission control.
Features

Built-in dual receiver
Dual buffered AV outputs
Can receive two different channels at the same time
Not affected by 2.4 GHz R/C Radios
AV Receiver with diversity inputs
Small, light weight, durable
Includes charger
Includes sun shade

Specifications

Screen size: 7 inches
Screen type: TFT LCD Screen/long life, LED backlight
Resolution: 800x480
Brightness: 450 cd/m2
Contrast: 500:1
View angle: 140/120 degree
Working voltage: DV 7-12 V (center positive) or 11.1 V Li-battery
Power consumption: < 8 w
Size: 180mm x 120 mm x 23 mm
Built-in 5.8 GHz dual diversity receiver automatically for best reception
Built-in 2CH 5.8 GHz AV output and 1-channel AV input
Multilanguage menu support
Working temperature: -10 degree to 65 degree centigrade

Working frequencies

CH1: 5705 MHz
CH2: 5685 MHz
CH3: 5665 MHz
CH4: 5645 MHz
CH5: 5885 MHz
CH6: 5905 MHz
CH7: 5925 MHz
CH8: 5945 MHz
